18 mm Series

An affordable and elite series, specially designed for low-rise buildings while offering a refined look and reliable performance.

18 mm
Profile series
12
Profiles in the range
0.42–1.05
Profile weights, kg/m
pp. 2–3
Product catalogue
/ 01 · Profile range

12 extruded profiles.

Section drawings from the Banco product catalogue. Dimensions in mm; weights in kg per metre.

SPS 2047401 0.481 kg/m
Section drawing of profile SPS 2047401, 0.481 kg/m
SPS 2047402 0.526 kg/m
Section drawing of profile SPS 2047402, 0.526 kg/m
ART 2029633 0.438 kg/m
Section drawing of profile ART 2029633, 0.438 kg/m
SPS 1047399 0.915 kg/m
Section drawing of profile SPS 1047399, 0.915 kg/m
SPS 1047400 1.055 kg/m
Section drawing of profile SPS 1047400, 1.055 kg/m
SPS 2047340 0.523 kg/m
Section drawing of profile SPS 2047340, 0.523 kg/m
ART 2029595 0.427 kg/m
Section drawing of profile ART 2029595, 0.427 kg/m
ART 2029596 0.421 kg/m
Section drawing of profile ART 2029596, 0.421 kg/m
SPS 1047321 0.425 kg/m
Section drawing of profile SPS 1047321, 0.425 kg/m
ART 1029594 0.502 kg/m
Section drawing of profile ART 1029594, 0.502 kg/m
SPS 1029906 0.539 kg/m
Section drawing of profile SPS 1029906, 0.539 kg/m
SPS 1029907 0.447 kg/m
Section drawing of profile SPS 1029907, 0.447 kg/m
/ 02 · Bill of materials

Aluminium for a 1.2 m × 1.2 m window.

Profiles, quantities and weights for one reference window, as specified in the catalogue.

Standard configuration

This table is being re-checked against the profile drawings. Refer to page 3 of the product catalogue in the meantime.

All Window systems Next → 25 mm Series
Architectural Series Product Catalogue
PDF · 42 pages · 81 MB · 18 mm Series on pp. 2–3
View catalogue (PDF)
