27 mm Slim Series

A high-performance, slim, and aesthetic series, best suited for residential bungalows and premium low-rise buildings.

27 mm
Profile series
9
Profiles in the range
13.55 kg
Aluminium · 1.2 m × 1.2 m window
pp. 10–11
Product catalogue
/ 01 · Profile range

9 extruded profiles.

Section drawings from the Banco product catalogue. Dimensions in mm; weights in kg per metre.

ART 1029835 0.741 kg/m
Section drawing of profile ART 1029835, 0.741 kg/m
ART 1029836 0.768 kg/m
Section drawing of profile ART 1029836, 0.768 kg/m
ART 1029837 0.561 kg/m
Section drawing of profile ART 1029837, 0.561 kg/m
ART 1029838 1.372 kg/m
Section drawing of profile ART 1029838, 1.372 kg/m
ART 1029839 1.176 kg/m
Section drawing of profile ART 1029839, 1.176 kg/m
ART 2029915 1.811 kg/m
Section drawing of profile ART 2029915, 1.811 kg/m
ART 1029859 0.559 kg/m
Section drawing of profile ART 1029859, 0.559 kg/m
ART 1029860 1.054 kg/m
Section drawing of profile ART 1029860, 1.054 kg/m
ART 1029840 0.104 kg/m
Section drawing of profile ART 1029840, 0.104 kg/m
/ 02 · Bill of materials

Aluminium for a 1.2 m × 1.2 m window.

Profiles, quantities and weights for one reference window, as specified in the catalogue.

Standard configuration
Profile Section no. kg/m Weight (kg) Qty Net weight (kg)
Shutter ART 1029835 0.741 0.889 6 5.334
SGU Interlock ART 1029837 0.561 0.673 1 0.673
Reinforcement ART 1029838 1.372 1.646 1 1.646
2 Track ART 1029839 1.176 1.411 4 5.644
U Type Track Rail ART 1029840 0.104 0.125 2 0.250
Total 13.547
