40 mm Casement Series

Name: Banco 40 mm Casement Series
Brand: Banco Aluminium

A slim, durable aluminium casement system offering high weather resistance and modern aesthetics.

40 mm

Profile series

Profiles in the range

0.22–1.57

Profile weights, kg/m

pp. 20–21

Product catalogue

/ 01 · Profile range

16 extruded profiles.

Section drawings from the Banco product catalogue. Dimensions in mm; weights in kg per metre.

ART 2029628 0.723 kg/m

ART 1029629 0.613 kg/m

ART 1029632 0.789 kg/m

ART 1029630 0.223 kg/m

ART 1029631 0.223 kg/m

ART 2029643 1.410 kg/m

ART 1029644 1.203 kg/m

ART 1029645 0.957 kg/m

ART 2029646 1.570 kg/m

ART 1029647 1.446 kg/m

ART 2029909 0.603 kg/m

ART 1029910 0.730 kg/m

ART 2029911 0.536 kg/m

ART 1029912 0.729 kg/m

ART 1029913 0.651 kg/m

ART 1029914 0.242 kg/m

/ 02 · Bill of materials

Profiles, quantities and weights for one reference window, as specified in the catalogue.

Standard configuration

This table is being re-checked against the profile drawings. Refer to page 21 of the product catalogue in the meantime.

Grill configuration

This table is being re-checked against the profile drawings. Refer to page 21 of the product catalogue in the meantime.

Architectural Series Product Catalogue

PDF · 42 pages · 81 MB · 40 mm Casement Series on pp. 20–21
